The Extech Model LCR200 LCR meter accurately measures capacitors, inductors, and resistors using the test frequencies of 100Hz, 120Hz, 1 kHz, 10 kHz, and 100 kHz. The dual display simultaneously displays the associated quality factor, dissipation, or phase angle value using a series or parallel equivalent circuit.
The Extech Model LCR200 is a dual display instrument designed to accurately measure capacitors, inductors, and resistors. It supports selectable serial or parallel modes with various test frequencies ranging from 100Hz to 100kHz. The device features an auto power-off function and includes options for relative measurements and component sorting.
| Display | 19,999/1 999 count dual LCD display |
|---|---|
| Test frequencies | 100Hz, 120Hz, 1kHz, 10kHz, 100kHz |
| Inductance range (L) | 0.00UH to 2000.0H |
| Capacitance range (C) | 0.0pF to 2.000 mF |
| Resistance range (R) | 0.000 to 200.0 MQ |
| Power Supply | 9V battery (Alkaline) |
| Operating temperature | 0°C to 50°C |
The meter supports five test frequencies: 100Hz, 120Hz, 1kHz, 10kHz, and 100kHz.
The default sorting tolerance is +/- 1%.
