CDCV304 is a PCI-X clock buffer produced by Texas Instruments. It operates at a frequency of 0MHz to 140MHz. The low output skew is less than 100ps. It can distribute one clock input to one bank of four output clocks. When OE is low, the output is low. CDCV304 operates at a voltage of 3.3V. It is suitable for automotive and industrial applications and has a working temperature range of -40°C to 85°C.
The CDCV304 is a high-performance, low-skew clock buffer designed for general-purpose and PCI-X applications. It distributes a single input clock signal to a bank of four outputs, operating from a single 3.3-V supply in an 8-pin TSSOP package. The device is characterized for operation from -40°C to 85°C, making it suitable for automotive and industrial environments.
| Operating Frequency | 0 MHz to 140 MHz |
|---|---|
| Output Skew | <100 ps |
| Supply Voltage | 3.3 V |
| Package Type | 8-Pin TSSOP |
| Operating Temperature Range | -40°C to 85°C |
The CDCV304 operates at frequencies up to 140 MHz.
The device operates from a single 3.3-V supply.
Yes, it is characterized for operation from -40°C to 85°C for automotive and industrial applications.
