ON CS5171 CS5172 CS5173 CS5174 1.5 A 280 kHz/560 kHz Boost Regulators handbook

This datasheet provides the features and specifications of CS5171, CS5172, CS5173, CS5174 1.5 A 280 kHz/560 kHz Boost Regulators

Brand: ON Semiconductor
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 22
File format: PDF
File size: 186 KB
Published: 12 July, 2012
Updated: 01 October, 2023
MD5 checksum: 90D5F9654A6EE5C8C0DB454ABCF7CA15
PDF: ON CS5171 CS5172 CS5173 CS5174 1.5 A 280 kHz/560 kHz Boost Regulators handbook PDF

About this manual

The CS5171/2/3/4 products are switching regulators featuring a high efficiency, 1.5 A integrated switch designed to operate over an input voltage range of 2.7 V to 30 V. These parts utilize current mode architecture and support various power supply configurations including boost, flyback, forward, inverting, and SEPIC topologies.

What's inside

Features
Maximum Ratings
Electrical Characteristics
Package Pin Description
Block Diagram

Specifications

Integrated Switch Current	1.5 A Guaranteed
Input Voltage Range	2.7 V to 30 V
Operating Frequency (CS5173/4)	560 kHz
Junction Temperature Range (Industrial)	-40°C to +125°C

Frequently asked questions

What is the shutdown current maximum?

The shutdown current is a maximum of 50 µA.

Are Pb-Free packages available?

Yes, Pb-Free Packages are available for these regulators.
