The FPF200X EVM is an Evaluation Module for Fairchild Semiconductor FPF2000 smart load switches family. The FPF200X family is a 0.7 Ω PMOS load switches with controlled turn-on, fast turn-off, and current limit. The current Limit is guaranteed for 50mA and 100mA with 1.8V to 5.5V range of input voltage. The Evaluation Module has test points for convenient access to the all pins and jumpers for setting the various load conditions along with switches for toggling the ON/OFF and configuring the ON pin polarity. The Board can be presented as a stand alone unit with a 1.8-5.5V battery for testing the basic functions.
The FPF200X Evaluation Module (EVM) is designed for the FPF2000 smart load switches family. It features a 0.72 PMOS load switch with controlled turn-on, fast turn-off, and current limit capabilities. The module allows for convenient access to all pins via test points and includes jumpers and switches for configuring load conditions, toggling ON/OFF states, and setting ON pin polarity. It can operate as a standalone unit with a 1.8V to 5.5V battery or be tested with external equipment.
| Input Voltage Range | 1.8V to 5.5V |
|---|---|
| Current Limit Guarantee | 50mA and 100mA |
| Switch Type | 0.72 PMOS load switches |
By removing resistor R3 (0Ω) and soldering a loop across it.
Using switch SW3, set to LO for FPF2001/FPF2005 and HI for other FPF200X models.
