AJA UDC Installation and Operation Guide

This document is the installation and operation guide for AJA's UDC 10-bit Up/Down/Cross Mini-Converter. The document describes the features and characteristics of the product.

Brand: AJA
Category: Other Electronics
Document type: User Manual
Language: English
Pages: 30
File format: PDF
File size: 1.7 MB
Published: 09 July, 2012
Updated: 29 September, 2023
MD5 checksum: 6B97FA1B7FF398C8182AA23AD9A81335
PDF: AJA UDC Installation and Operation Guide PDF

About this manual

The AJA UDC is a broadcast quality Up/Down/Cross Mini-Converter designed to convert between SD, HD, and 3G video formats. It supports high-quality conversions at various resolutions including 1080p50/60 and features 16-channel embedded SDI audio input and output. The device can be controlled via local DIP switches or through the USB port using the Mini Config software application.

What's inside

Introduction
Video Formats
Features
Block Diagram
I/O Connections
Installation
User Controls
Mini Config Operation
DIP Switches
Specifications

Specifications

Power Supply	+5 to +20V DC
Warranty Period	five years
Video Formats Supported	SD, HD, 3G
Audio Channels (SDI)	16-channel

Frequently asked questions

What is the function of Switch 1 on the DIP switch panel?

Switch 1 controls the CONTROL mode, selecting between Local and Remote operation.

What is the UDC and what video formats does it convert between?

The UDC is a broadcast quality Up/Down/Cross Mini-Converter that converts between SD, HD, and 3G video formats.

What power voltage range does the unit require?

The unit uses +5 to +20V power.
