This file introduces important safeguards for B/W CCD Camera, including warnings, cleaning instructions, do not use attachments not recommended by the appliance manufacturer, do not place the product near water, etc.
The document serves as an instruction manual for the EverFocus ED100, a compact full-functioned B/W CCD dome camera. It features a 1/3" Sony B/W CCD sensor with DSP, Auto Electronic Shutter, and Automatic Gain Control. The device is designed to be mounted on ceilings or walls using a supporting bracket.
| Pickup Device | 1/3" SONY BAW CCD |
|---|---|
| Horizontal Resolution | 420 TV lines |
| Sensitivity | 0.04 Lux /F=1.2 |
| Electronic Shutter | 1/60~1/100,000 |
| Video Output | BNC 1.0Vp-p,75 ohm |
| Power Source | 12VDC |
| Dimensions | 108 mm (O.D.) x 80 mm (H) |
The camera operates between 0°C and +50°C.
No, the manual states that outdoor application without shielding is not recommended.
