Agilent V250 vs V301 Pumps Technical Memo

Q: What is the major technical advantage of the V301 pump?

The V301 offers low power consumption for improved performances at higher foreline pressure, ensuring better reliability and lower working temperatures.

Q: What is the recommended baking pump for the V250?

The recommended baking pump for the V250 is the Diaphragm MDP30.

Q: What is the cooling method for the V250 and V301 pumps?

Both the V250 and V301 pumps use Air cooling.

This document is a technical memo about the upgrade of V250 series pumps and V301 series pumps

Agilent V250 vs V301 Pumps Technical Memo - cover page

Brand: Agilent
Category: Industrial Supply
Document type: Product Leaflet
Language: English
Pages: 15
File format: PDF
File size: 295 KB
Published: 05 July, 2012
Updated: 30 September, 2023
MD5 checksum: 98AE2A61226E4C3012E46F4313A62B1F
PDF: Agilent V250 vs V301 Pumps Technical Memo PDF

About this manual

This document provides a technical comparison between the Agilent V250 Series and V301 Series pumps. It includes outline drawings, technical specifications, and performance curves for both models, specifically comparing their dimensions, pumping speeds, and compression ratios.

What's inside

Outline drawings
Technical Specification
Pumping Speed Curve
Power consumption curve
Technical Specifications
Motor technology
Technical Advantages
Interconnection schematic

Specifications

Pumping speed (N2)	250 I/s
Pumping speed (He)	220 I/s
Pumping speed (H2)	200 I/s
Ultimate pressure (With rotary)	<5x10e-10 mbar
Rotational speed	56000
Power consumption	90 W
Noise level	45 dB (A) at 1 meter

Frequently asked questions

What is the major technical advantage of the V301 pump?
