S5K3A1EA is a 1/3 inch SXGA CMOS image sensor produced by SAMSUNG with 1280x1024 effective pixels. It is manufactured using a 0.18um CMOS process and has a 10-bit ADC block to digitize pixel output and an on-chip CDS to significantly reduce fixed pattern noise (FPN).
The Samsung SSK3A1EA is a highly integrated single-chip CMOS image sensor fabricated using 0.18um CMOS process technology. It features a 1/3 inch optical size with 1280 x 1024 effective pixels and includes on-chip 10-bit ADC blocks and correlated double sampling (CDS) to reduce fixed pattern noise.
| Effective Resolution | 1280 x 1024, SXGA |
|---|---|
| Optical Size | 1/3 inch |
| Unit Pixel Size | 3.8 um X 3.8 um |
| Process Technology | 0.18um Dual Gate Oxide SPQM CMOS |
| Operating Temperature | -20 to +60 °C |
| Analog Supply Voltage | 2.8V |
| Digital Supply Voltage | 1.8V |
| Package Type | 48-CLCC/PLCC |
The sensor has 1280 x 1024 effective pixels.
The unit pixel size is 3.8 um X 3.8 um.
It uses a dual power supply of 2.8V for analog and 1.8V for digital.
