The document describes the Toshiba TB6504F, an integrated circuit designed as a PWM chopper type sinusoidal micro step bipolar stepping motor driver. It utilizes high voltage Bi-CMOS process technology to provide output currents up to 150mA and supports both forward and reverse rotation.
| Product Type | PWM chopper type sinusoidal micro step bipolar stepping motor driver |
|---|---|
| Output Current | up to 150mA |
| Package Type | SSOP24-P-300-1.00 |
| Process Technology | high voltage Bi-CMOS process technology |
The device supports 2, 1-2, W1-2, or 2W1-2 phase 1 or 2 clock drives.
The typical weight of the TB6504F is 0.329g.
