This document describes a 184-pin unbuffered dual-in-line memory module using DDR SDRAM technology. It includes the features and characteristics of the product.
![lnfineon HYS[64/72]D64x20HU-[5/6]-C HYS[64/72]D32x00HU-[5/6]-C HYS64D16x01HU-[5/6]-C 184-Pin Unbuffered Dual-In-Line Memory Modules Reg DIMM DDR SDRAM - cover page](/uploads/covers/6f/6f98267ab597539fa161041fdf751b96.jpg)
This datasheet describes the HYS[64/72]D64x20HU-[5/6]-C, HYS[64/72]D32x00HU-[5/6]-C, and HYS64D16x01HU-[5/6]-C industry standard 184-Pin Unbuffered Dual-In-Line Memory Modules (Reg DIMM). These modules are organized as 16M x 64, 32M x 64, 32M x 72, and two ranks of 64M x 64 or 64M x 72 for non-parity and ECC main memory applications. They utilize 256 Mbit DDR SDRAM in a P-TSOPII-66-1 package.
| Module Type | 184-Pin Unbuffered Dual-In-Line Memory Modules (Reg DIMM) |
|---|---|
| Organization | One rank 16M x 64, 32M x 64, 32M x 72 and two ranks 64M x 64, 64M x 72 |
| Power Supply | +2.5V (+0.2V) |
| DRAM Package | P-TSOPII-66-1 |
| Form Factor Dimensions | 133.35 mm x 31.75 mm x 4.00 mm max. |
| Max Clock Frequency (CL=3) | 200 MHz |
| Max Clock Frequency (CL=2.5) | 166 MHz |
The modules support DDR400 Speed Grade (PC3200) and PC2700.
They are available as both ECC and non-parity configurations depending on the specific part number.
