MtronPTI M611x Series is 5 x 7 mm, 3.0, 3.3 & 5.0 Volt, HCMOS or Clipped Sinewave, Precision TCXO/TCVTCXO, with 0.3 ppm tight stability over wide industrial temperature range (-40 °C to +85 °C), available in 3.0 V, 3.3 V and 5.0 V versions, frequency range from 8 MHz to 52 MHz, ideal for applications such as GPS, military, avionics, test and measurement, WLAN, WiMax base stations (see Fig 2.), point to point/multi-point radios, medical equipment, frequency synthesis, fre- quency translation and land mobile radio.
The MtronPTI M611x Series consists of low-voltage, surface-mount Precision Temperature Compensated Crystal Oscillators (TCXOs) and Voltage Controlled TCXOs (TCVTCXOs). These devices are designed for applications where timing accuracy is critical, offering extremely tight stability of 0.3 ppm over a wide industrial temperature range from -40 °C to +85 °C.
| Frequency Range | 8 to 52 MHz |
|---|---|
| Operating Temperature | -40 °C to +85 °C |
| Frequency Stability | +0.3 ppm |
| Supply Voltage Options | 3.0 V, 3.3 V, 5.0 V |
| Package Size | 5 x 7 mm |
| Supply Current (HCMOS @ 13 MHz) | 2.2 mA typical |
| Output Types | HCMOS or Clipped Sinewave |
The M611x Series offers 3.0 V, 3.3 V, and 5.0 V versions.
The series provides tight stability of 0.3 ppm over a wide industrial temperature range.
Yes, the package is RoHS Compliant.
