This data sheet provides the mechanical and electrical specifications for the SPC10523 cable assembly, including dimensions, connector types, and material finishes. Revision history and drawing references are also listed.
Key information includes the pinout layout, cable construction (28 AWG, 25 pairs), insulation color, jacket material, and plating details for the connectors.
| Cable gauge | 28 AWG (7/0.127) |
|---|---|
| Number of pairs | 25 pairs |
| Insulation color | Black |
| Jacket material | 80°C PVC |
| Connector 1 pin count | 50‑pin male |
| Connector 2 pin count | 68‑pin male |
| Connector plating | Nickel plating |
| Connector color | Platinum gray |
The insulation color is black.
The jacket is made of 80°C PVC.
The cable contains 25 pairs of conductors.
