This document describes the specifications and features of SPC SPC TECHNOLOGY DB25M and HPCN36M connectors, including color coding and pinouts.
This document is a technical datasheet for the SPC Technology model SPC10448, an IEEE 1284 compliant printer cable. The product measures 10 feet in length and connects via a male DB25 connector on one end and a male HPCN36 connector on the other.
The specification details include construction requirements such as a tin braid shield, 28 AWG (7/0.127) wire for the 18 pairs, and an 80°C PVC jacket with an outer diameter of 27.5+0.15mm.
| Length | 10 FT |
|---|---|
| Wire Gauge | 28AWG (7/0.127) |
| Pairs | 18 Pairs |
| Jacket Temperature Rating | 80°C |
| Connector Type B | HPCN36 Pin Male |
