ASRock H71M-DG3 is a Micro ATX motherboard that supports third and second generation Intel Core i7/i5/i3 processors. The motherboard features all-solid capacitor design for stable and reliable performance.
This guide introduces the ASRock H71M-DG3 Micro ATX motherboard, its supported CPUs, memory, and expansion options. It includes detailed installation instructions, connector pin‑outs, and recommended BIOS settings.
The document also lists technical specifications, audio and networking features, SATA and USB interfaces, and environmental compliance information, helping users assemble and configure the board safely and efficiently. This manual is written in Chinese.
| Form factor | Micro ATX (8.9" x 6.8") |
|---|---|
| Chipset | Intel® H61 |
| Maximum memory | 16 GB (2 DDR3 DIMM slots) |
| PCI Express slots | 1 × PCIe 3.0 x16, 1 × PCIe x1 |
It supports Microsoft Windows 7/7 64‑bit, Vista, Vista 64‑bit, XP and XP 64‑bit.
The motherboard has two DDR3 DIMM slots and can support up to 16 GB of system memory.
It provides one PCI Express 3.0 x16 slot (blue) and one PCI Express x1 slot.
