ASRock H61M-VGS R2.0 / H61M-VS R2.0 is a Micro ATX motherboard from ASRock, supporting the third and second generation Intel Core i7 / i5 / i3 processors, supporting DDR3 1600/1333/1066 non-ECC, un-buffered memory, and supporting up to 16GB of system memory.
This guide provides step‑by‑step instructions for installing the ASRock H61M-VGS R2.0 and H61M-VS R2.0 motherboards, including package contents, hardware connections, BIOS setup, and safety notes.
It also details the board’s specifications such as CPU socket, memory support, expansion slots, storage interfaces, networking, audio, and BIOS features, helping users configure the system for optimal performance. This manual is written in Chinese.
| Form factor | Micro ATX |
|---|---|
| Dimensions | 8.9 x 6.8 inches (22.6 x 17.3 cm) |
| CPU socket | LGA1155 |
| Memory type | DDR3, dual‑channel, non‑ECC, un‑buffered |
| Memory speed | DDR3‑1600 / DDR3‑1333 / DDR3‑1088 |
| SATA ports | 4 × SATA2 3.0 Gb/s (supports NCQ, AHCI) |
| Audio codec | VIA VT1705 5.1‑channel HD Audio |
| BIOS | 32 Mb AMI BIOS, UEFI Legacy BIOS with GUI |
It uses an LGA1155 socket.
It includes a Realtek RTL8111E Gigabit Ethernet controller.
There are four SATA2 ports supporting up to 3.0 Gb/s with NCQ and AHCI.
