ASRock H61M-HGS Motherboard Installation Guide

Brand: ASRock
Category: Motherboard
Document type: Installation Guide
Language: English
Pages: 48
File format: PDF
File size: 849 KB
Published: 04 June, 2012
Updated: 30 September, 2023
Model: H61M-HGS
MD5 checksum: 3288522894A14437181F3C21F6AEDD0F
PDF: ASRock H61M-HGS Motherboard Installation Guide PDF

About this manual

This guide introduces the ASRock H61M-HGS motherboard, a Micro ATX board with an Intel H61 chipset, dual‑channel DDR3 memory support, and a range of I/O connectors. It includes a quick‑start overview, package contents, and safety notices.

Detailed sections cover the motherboard layout, I/O panel, rear panel connectors, BIOS features, and installation cautions. The guide also points to the full user manual on the support CD for advanced configuration and driver installation.

What's inside

Introduction
Package Contents
Specifications
Motherboard Layout
I/O Panel
Rear Panel I/O
BIOS Setup
Caution
Warning
Installation Steps

Specifications

Form Factor	Micro ATX
CPU Socket	1155‑Pin
Chipset	Intel H61
Memory Slots	2 DDR3 DIMM slots
Maximum Memory Capacity	16 GB
SATA Connectors	4 SATA2 (3.0 Gb/s) ports
LAN	Realtek RTL8111E Gigabit Ethernet
Audio Codec	VIA VT1705 5.1 CH HD Audio
BIOS	32 Mb AMI BIOS with UEFI GUI

Frequently asked questions

What CPU socket does the H61M‑HGS motherboard use?

It uses a 1155‑Pin LGA1155 CPU socket.

How many DDR3 memory slots are available?

The board provides two DDR3 DIMM slots.

Does the motherboard support HDMI output?

Yes, it includes an HDMI port that supports HDMI 1.4a.
