This document provides information about the usage, specifications, design features, and installation steps of the H71M-DGS motherboard by ASRock. It also includes a guide for the UEFI setup program.
This manual introduces the ASRock H71M-DGS motherboard, its packaging contents, and detailed specifications such as form factor, CPU socket, chipset, memory support, and expansion slots. It also describes the board layout, rear panel connectors, and supported audio, LAN, and storage interfaces.
The guide walks users through installation procedures, BIOS/UEFI configuration, driver installation, and supported operating systems. Safety warnings, jumper settings, and troubleshooting tips are included to help users achieve stable performance. This manual is written in Chinese.
| Form factor | Micro ATX (8.9" x 6.8") |
|---|---|
| CPU socket | LGA1155 |
| Chipset | Intel H61 |
| Memory slots | 2 DDR3 DIMM slots |
| Maximum memory | 16 GB DDR3 |
| PCI Express slots | 1 × PCIe 3.0 x16, 1 × PCIe x1 |
| SATA ports | 4 × SATA2 3.0 Gb/s |
| LAN controller | Realtek RTL8111C Gigabit |
| Audio codec | Realtek ALC662 5.1‑channel |
| BIOS | 32 Mb AMI UEFI BIOS |
The rear panel provides six usable USB 2.0 ports.
It is a Micro ATX board measuring 8.9 inches by 6.8 inches.
