ASRock Z77 Extreme4 Motherboard is one of the ASRock Z77 series motherboards, supports third and second generation Intel Core i7/i5/i3 processors, equipped with 8+4 power phase design, supports Intel Turbo Boost 2.0 technology and Intel Fast Boot technology
This manual introduces the ASRock Z77 Extreme4 motherboard, its packaging contents, and step‑by‑step installation guidance. It also points users to the ASRock website for the latest BIOS and driver updates.
The document details the board’s specifications, including CPU support, memory capacity, expansion slots, connectors, audio and networking features, as well as BIOS configuration, quick‑switch functions, and safety warnings. This manual is written in Chinese.
| Form factor | ATX (12.0 in x 8.6 in) |
|---|---|
| CPU socket | LGA1155 |
| Chipset | Intel Z77 |
| Memory slots | 4 DDR3 DIMM slots |
| Maximum memory | 32 GB |
| LAN | Gigabit Ethernet (Broadcom BCM57781) |
| Audio codec | Realtek ALC898 |
Press during the POST to enter the BIOS setup program.
It supports Windows 7/7 64‑bit, Vista/ Vista 64‑bit, XP and XP 64‑bit.
