ASRock Z77 Pro4-M Motherboard is a Micro ATX form factor motherboard that supports the third and second generation Intel ® Core TM i7 / i5 / i3 processors (LGA1155 pin), supports dual channel DDR3 memory technology, and supports up to 32GB system capacity.
This guide explains how to install and configure the ASRock Z77 Pro4-M motherboard. It covers packaging contents, required tools, BIOS settings, and software utilities needed for a successful build.
Key hardware features are detailed, including CPU socket support, memory capabilities, expansion slots, storage interfaces, audio and networking components, as well as power and cooling options. The document also describes BIOS functions, over‑clocking utilities, and safety information. This manual is written in Chinese.
| Form factor | Micro ATX 9.6" x 9.6" (24.4 cm x 24.4 cm) |
|---|---|
| LAN | Gigabit Ethernet, Realtek RTL8111E |
The board follows the Micro ATX form factor, measuring 9.6 inches by 9.6 inches (24.4 cm × 24.4 cm).
