This document describes the features and characteristics of the ASRock H61DE/S3 motherboard, including its reliable quality and stability, as well as the supported processors and memory technology.
This manual introduces the ASRock H61DE/S3 motherboard, its ATX form factor, supported CPUs, memory types, and built‑in features. It provides step‑by‑step instructions for installing the board, connecting power, SATA, USB and other interfaces, and configuring BIOS settings.
Additional sections cover jumpers, power‑management options, software utilities such as Instant Flash and XFast features, and environmental compliance information. This manual is written in Chinese.
| Form factor | ATX 12.0" x 8.6" (30.5 cm x 21.8 cm) |
|---|---|
| CPU socket | LGA1155 |
| Chipset | Intel H61 |
| Memory slots | 4 DDR3 DIMM slots |
| Supported memory types | DDR3 1600/1333/1066 non‑ECC, unbuffered |
| Maximum memory capacity | 16 GB |
The board supports Windows 7/7 64‑bit, Windows Vista 64‑bit, and Windows XP/XP 64‑bit.
Press during power‑on to launch the BIOS configuration utility.
It uses a 24‑pin ATX power connector, an 8‑pin 12 V CPU power connector, and includes SATA power connectors.
