ASRock Z77 Pro3 motherboard manual, introduces the functions and features of the motherboard, specifications, installation steps, etc.
This guide covers everything needed to install the ASRock Z77 Pro3 motherboard, from unpacking and checking the package contents to mounting the board, connecting power, and attaching peripherals. It also explains BIOS setup, jumper settings, and the use of ASRock utilities for tuning and system monitoring.
Key sections include detailed specifications, rear panel I/O descriptions, BIOS features, jumper and CMOS reset procedures, safety warnings, and regulatory information. The document is written in Chinese and includes diagrams and tables to aid the installation process.
| Form factor | ATX (12.0" x 7.6") |
|---|---|
| CPU socket | LGA1155 |
| PCI Express slots | 1 × PCIe 3.0 x16, 1 × PCIe 2.0 x16, 1 × PCIe 2.0 x1, 2 × PCIe x1 |
| SATA ports | 2 × SATA3 6 Gb/s, 4 × SATA2 3 Gb/s |
| LAN | Realtek RTL8111E Gigabit Ethernet, Wake‑On‑LAN, Energy Efficient Ethernet |
| BIOS | 64 Mb AMI UEFI Legacy BIOS with GUI |
The motherboard uses an LGA1155 socket.
It provides two SATA3 6 Gb/s ports and four SATA2 3 Gb/s ports.
