This document describes the features and characteristics of Arcolectric products, including options for colors, printing legends, and lamp voltages. It also provides dimensions and installation requirements for different models.
This leaflet describes the Arcolectric 8620 and 8670 rocker switches, which are 3‑position switches rated at 10 A and 250 Vac. It includes body types, panel cut‑out requirements, and available options such as finishes, colours, legend printing, and protective covers.
Technical data such as panel thickness ranges, terminal spacing, contact gap, and IP‑rated protective covers are listed, along with dimensions for snap‑in fixing for both single‑pole and double‑pole configurations.
| Contact gap | 2 mm |
|---|---|
| Terminal spacing | 6.0 mm (1‑3), 9.5 mm (2‑4) |
| Protective cover | L167 (IP65) for single pole, L180 (IP65) for double pole |
| Finish | Matt finish only |
A protective cover L167 is available for single‑pole switches and L180 for double‑pole switches, both designed to IP65.
Panel cut‑outs must be punched in the direction of insertion.
