This document is an introduction to Altera's Stratix V devices, focusing on device interfaces and integration. The devices have innovative features and capabilities.
This handbook covers the architecture and features of Altera Stratix V devices. It includes chapters on Logic Array Blocks, Adaptive Logic Modules, embedded memory blocks, variable‑precision DSP blocks, clock networks and PLLs, I/O standards, high‑speed differential interfaces, external memory interfaces, hot‑socketing, power‑on reset, configuration, design security, remote system upgrades, SEU mitigation, and JTAG boundary‑scan testing.
The document also provides typographic conventions, revision history, and contact information for Altera technical support and product literature. It is intended for designers and engineers working with Stratix V FPGAs.
| Device family | Stratix V |
|---|---|
| Document code | SV5V1-1.7 |
Bold type with initial capital letters indicates command names, dialog box titles, dialog box options, and other GUI labels.
Caution calls attention to a condition or possible situation that can damage or destroy the product or your work.
