This document describes the features and specifications of the PC terminal block SMKDS 1/ 5-3,5 from PHOENIX CONTACT GmbH & Co. KG. The product has 10 positions, a nominal current of 10A, a nominal voltage of 160V, a screw connection, soldering assembly, and a conductor/PCB connection direction of 55°. The color is green.
The SMKDS 1/5-3,5 is a 5‑position PC terminal block with a 3.5 mm pitch, rated for 10 A and 160 V. It features a green housing, screw connection, and can be assembled by soldering.
The handbook lists commercial data, technical dimensions, electrical ratings, certifications (CB, CCA, CSA, CUL, UL, etc.), and accessories such as marker cards and screwdrivers. It also includes drawing information for drilling and solder pad geometry.
| Nominal voltage | 160 V |
|---|---|
| Pitch | 3.5 mm |
| Number of positions | 5 |
| Length | 10 mm |
| Weight per piece | 0.003086 kg |
It has 5 positions.
The pitch is 3.5 mm.
It is certified by CB, CCA, CSA, CUL, GOST, SEV, and UL.
