The A55M-VS Trial is Asrock's Micro ATX motherboard based on AMD A55 FCH (Hudson-D2) chipset, supporting Socket FM1 100W processors, supporting dual-channel DDR3 2400+ (overclocked) memory technology, supporting AMD Dual Graphics technology, 5.1 sound high-fidelity audio (ALC 662 audio codec), supports THX TruStudioTM, supports 10/100 Ethernet, supports Turbo Boost Extreme Memory, Turbo Boost Extreme Network, Turbo Boost Extreme Network, supports AMD Steady VideoTM: The latest video post-processing capabilities, can provide automatic reduction for home / online video.
The ASRock A55M-VS is a Micro ATX motherboard that supports AMD FM1 socket processors and dual‑channel DDR3 2400+ memory. It features solid‑state capacitors for CPU power, a Realtek ALC662 5.1‑channel audio codec with THX support, and integrated AMD Dual Graphics technology.
The board includes 2 SATA ports, 4 USB 2.0 ports, a 10/100 Ethernet interface, and an AMI UEFI BIOS with 32 MB flash. It complies with ACPI 1.1 and ships with trial versions of CyberLink MediaEspresso and MAGIX multimedia suites. This manual is written in Chinese.
| Form factor | Micro ATX |
|---|---|
| CPU socket | FM1 |
| CPU power design | Solid‑state capacitors |
| Memory type | DDR3 2400+ dual‑channel |
| Audio codec | Realtek ALC662 |
| Audio channels | 5.1 |
| Ethernet | 10/100 Mbps |
| SATA ports | 2 |
| USB 2.0 ports | 4 |
| BIOS | AMI UEFI 32 MB |
| ACPI version | 1.1 |
| Dual Graphics support | AMD Dual Graphics |
| Included software | CyberLink MediaEspresso 6.5 trial, MAGIX suite |
It supports the AMD FM1 socket.
Yes, it supports AMD Dual Graphics technology.
The motherboard provides four USB 2.0 ports.
It uses the Realtek ALC662 codec with 5.1‑channel audio.
