This document introduces a Micro ATX motherboard that supports Socket FM1 100W processors and AMD Cool 'n' Quiet cooling and silent technology. The motherboard features dual-channel DDR3 memory technology with a maximum capacity of 16GB. It also supports AMD dual graphics and AMD Radeon HD 65XX/64XX graphics cards. The motherboard has HDMI and D-Sub dual display output interfaces, supporting 1080p Blu-ray disc playback and Blu-ray 3D. In addition, the motherboard features 5.1 channel high-fidelity audio and PCIE x1 Gigabit LAN.
The ASRock A55M-HVS motherboard supports Socket FM1 100W processors and up to 16 GB of DDR3 memory with dual‑channel 2400+ MHz (over‑clock) capability. It offers a range of expansion slots including one PCI Express 2.0 x16, one PCI Express 2.0 x1, and a legacy PCI slot, and supports AMD dual‑graphics with Radeon HD 6500/6600 series cards.
Connectivity features include HDMI 1.4a (max resolution 1920 × 1200 @ 60 Hz), D‑Sub, six USB 2.0 ports, six SATA2 ports with RAID 0/1/10 support, and a Realtek RTL8111E gigabit Ethernet controller with Wake‑On‑LAN and Energy Efficient Ethernet. Audio is handled by a VIA VT1705 5.1‑channel codec with THX TruStudio support. This manual is written in Chinese.
| CPU socket | Socket FM1 (100 W) |
|---|---|
| Maximum memory capacity | 16 GB DDR3 |
| Memory channels | Dual‑channel DDR3 |
| Supported memory speed | DDR3 2400+ MHz (over‑clock) |
| PCI Express slots | 1 × PCIe 2.0 x16, 1 × PCIe 2.0 x1 |
| Graphics support | AMD Radeon HD 6500/6600 series (dual‑graphics) |
| HDMI version | HDMI 1.4a |
| Network controller | Realtek RTL8111E Gigabit Ethernet |
| USB ports | 6 × USB 2.0 |
It supports Socket FM1 for 100 W processors.
The motherboard provides six USB 2.0 ports.
Yes, it supports AMD dual‑graphics with Radeon HD 6500/6600 series cards.
The board can handle up to 16 GB of DDR3 memory.
