The document introduces the features and characteristics of the ASRock Intel® H61 ��� H71M-DGS motherboard, including support for Intel� K series processors, dual-channel DDR3 1600 memory, PCIE Gigabit LAN, Intel� HD Graphics Built-in Visuals, etc.
This guide covers the key features of the ASRock H71M-DGS motherboard, including supported CPUs, memory configurations, expansion slots, and onboard I/O. Detailed tables list the specifications for each component, such as CPU socket type, maximum memory capacity, and supported graphics interfaces.
The manual also describes BIOS options, software utilities, and troubleshooting tips. It explains how to configure Intel Hyper-Threading, XMP memory profiles, and integrated graphics settings, as well as how to use the provided utilities for system monitoring and performance tuning.
| CPU socket | LGA1155 |
|---|---|
| Supported CPUs | 2nd and 3rd Gen Intel Core i7 |
| Memory slots | 2 x DDR3 |
| Maximum memory | 16 GB |
| Memory speed | DDR3 1600 MHz |
| Audio codec | Realtek ALC662 5.1‑channel |
| LAN | Realtek 10/100/1000 Mb/s |
| SATA ports | 4 x SATA2 (3.0 Gbps) |
| USB ports | 5 x USB 2.0 |
| BIOS type | AMI UEFI BIOS |
| Power connectors | 24‑pin ATX, 4‑pin 12V |
It uses an LGA1155 socket.
The board supports up to 16 GB of DDR3 memory.
