This document introduces a motherboard that supports Intel processors and dual-channel DDR3 memory, with high-speed USB, network, and audio functionality. It also supports a graphical UEFI BIOS interface, with stable performance and multiple interface options.
The H61M-VS R2.0 is a Micro ATX motherboard that supports LGA1155 sockets for first‑generation Intel Core i7, i5 and i3 processors. It offers dual‑channel DDR3 memory with two slots, up to 16 GB total, and includes a PCI Express x16 slot, a PCI Express x1 slot, and four SATA2 connectors.
Key features include Intel Turbo Boost 2.0, ASRock XFast USB (Turbo Boost) technology, VIA VT1705 5.1‑channel audio, Realtek RTL8105E 10/100 LAN, six USB 2.0 ports, and an AMI UEFI BIOS with ACPI 1.1, Wake‑On‑LAN and other power‑management options. The manual also lists bundled software such as CyberLink MediaEspresso and ASRock utilities. This manual is written in Chinese.
| Form factor | Micro ATX |
|---|---|
| CPU socket | LGA1155 |
| Supported CPUs | First‑generation Intel Core i7 / i5 / i3 |
| Memory slots | 2 x DDR3 |
| Maximum memory | 16 GB |
| Memory type | DDR3 1333/1600 |
| Audio codec | VIA VT1705 5.1‑channel |
| LAN controller | Realtek RTL8105E 10/100 |
| USB ports | 6 x USB 2.0 |
It uses an LGA1155 socket that supports first‑generation Intel Core i7, i5, and i3 processors.
It includes a VIA VT1705 5.1‑channel high‑fidelity audio codec.
