P67 Transformer is a motherboard produced by ASRock, which is based on Intel® P67 chipset and supports Intel® Lynnfield CoreTM i7/i5 processors, with 8 valve boost CPU power design, supports Intel® Turbo Boost technology, Hyper-Threading hyper-threading technology, asynchronous overclocking technology, supports dual channel DDR3 memory technology, equipped with 4 DDR3 DIMM slots, supports DDR3 2600+(overclock)/2133(overclock)/1866(overclock)/1600/1333/1066 non-ECC, un-buffered memory, supports up to 16GB system capacity, supports Intel® Extreme Memory Profile.
The ASRock P67 Transformer (P67变形金刚) is a high‑performance ATX motherboard built around the Intel® P67 chipset. It supports Intel Lynnfield Core i7/i5 processors (LGA1156) and up to 16 GB of DDR3 memory across four DIMM slots. The board features a full set of I/O including USB 3.0, SATA 3, HDMI / SPDIF, and a Realtek RTL8111E Gigabit LAN controller, plus a range of software utilities such as the ASRock Extreme Tuning Utility (AXTU) and SmartView.
The manual covers hardware specifications, BIOS/UEFI features, installation steps, and the bundled software suite (CyberLink DVD, Creative Sound Blaster, etc.). It also explains the SmartView Internet start page, power‑saving options, and advanced over‑clocking functions, providing end‑users and technicians with the information needed to set up and maintain the system. This manual is written in Chinese.
| CPU socket | LGA1156 |
|---|---|
| Supported processors | Intel® Lynnfield Core i7/i5 |
| Memory type | DDR3 |
| Maximum memory capacity | 16 GB |
| DIMM slots | 4 |
| PCI Express x16 slots | 1 (blue) |
| PCI Express x1 slots | 3 |
| PCI slots | 2 |
| SATA2 ports | 5 |
| SATA3 ports | 2 |
| Gigabit LAN controller | Realtek RTL8111E |
| USB 3.0 ports | 2 |
| USB 2.0 ports | 6 |
| HDMI / SPDIF connector | 1 HDMI_SPDIF |
It uses the LGA1156 socket for Intel Lynnfield Core i7 and i5 processors.
The motherboard includes two USB 3.0 ports.
It features a Realtek RTL8111E Gigabit LAN controller.
The board supports up to 16 GB of DDR3 memory.
