The HSMP-389x & HSMP-489x Series Surface Mount RF PIN Switch Diodes Data Sheet introduces the characteristics of the products, such as unique configurations, surface mount packages, low capacitance, low resistance, low failure rate, matched diodes, and higher power dissipation.
The handbook introduces the HSMP‑389x and HSMP‑489x series of surface‑mount RF PIN switch diodes, highlighting low resistance, low capacitance, and ultra‑low parasitic inductance for high‑frequency applications.
It includes electrical specifications, package dimensions, performance graphs, ordering options, and handling and soldering guidelines for designers and manufacturers.
| Forward Current (A) | 1 |
|---|---|
| Junction Temperature (°C) | 150 |
| Storage Temperature (°C) | -65 to 150 |
| Typical Package Inductance (nH) | 2 |
