This document introduces the features and characteristics of the C series chip capacitors, including high capacitance, mechanical strength and reliability, high-precision automatic assembly, extremely low stray capacitance, low residual inductance, long life and high reliability
The TDK C Series offers high‑capacitance multilayer ceramic chip capacitors with a monolithic structure for superior mechanical strength and reliability. Precision manufacturing enables thin dielectric layers, low stray capacitance and excellent frequency characteristics, making them suitable for high‑frequency and high‑density power‑supply designs.
The series includes a range of package sizes (0603, 1005, 1608, 2012, 3225, 4532, 5750) with various temperature‑characteristic classes (Class 1, Class 2) and rated voltages from 6.3 V up to 50 V. Detailed part numbers specify capacitance, tolerance, voltage and temperature class for each size.
| Rated voltage (example) | 6.3 V |
|---|---|
| Package dimensions (0603) | 0.6 × 0.3 mm |
| Capacitance coding | Three‑digit code: first two digits are significant figures, third digit is multiplier |
| Temperature class (Class 1) | Temperature compensation |
C0603 capacitors are rated at 6.3 V.
The 0603 package measures 0.6 mm × 0.3 mm.
