NETGEAR GS724T ProSafe 24 Port Gigabit Smart Switch is a member of NETGEAR's Smart Switch family that provides simple switch management at no extra cost. This 24-port Gigabit switch is high on value and capability. It has 24 10/100/1000 Mbps ports, each capable of powering 2000 Mbps of data throughput in full-duplex mode, plus two optional fiber ports, providing fast backbone and connecting servers or power users. It delivers large amounts of multimedia, image, and video information in no time at all. Ideal for combining 10, 100, and 1000 Mbps devices, it delivers 10/100/1000 automatic speed and full/half-duplex sensing plus Auto Uplink™ on every port. Two hot-swappable Small Form factor Pluggable (SFP)** GBIC slots provide optional fiber connectivity for greater distance. In addition, an intuitive, Web-browser interface offers the simple Smart Switch management, making it a snap to monitor switch performance, configure ports, even set up port trunks, VLANs, and traffic prioritization. Alternatively, use SNMP-based software to manage your Smart Switch. It delivers switching that's easy to set up and use.
This manual covers the features, installation, and configuration of the NETGEAR GS724T 24‑port Gigabit Smart Switch. It explains how to connect devices, use the web‑based management interface, and enable advanced functions such as VLANs, port trunking, and QoS.
Technical specifications, environmental ratings, safety approvals, and warranty information are also included, along with a list of accessories and related products to help you expand your network.
| Ports | 24 RJ‑45 10/100/1000 Mbps |
|---|---|
| SFP Slots | 2 |
| Bandwidth | 48 Gbps |
| Power Consumption | 29 W max |
| Dimensions | 1.7 × 17.3 × 8.1 in (43 × 440 × 205 mm) |
| Weight | 5.9 lb (2.7 kg) |
| MTBF | 115,221 hours (~13 years) |
| Buffer Memory | 256 KB embedded per unit |
The GS724T provides 24 RJ‑45 ports supporting 10/100/1000 Mbps speeds.
Yes, it supports IEEE 802.1Q Tag VLAN with up to 64 static VLAN groups.
The switch consumes up to 29 W of power.
