NETGEAR FVS338 is a VPN firewall with 8 ports, 10/100Mbps, supports 50 VPN tunnels, and can realize encrypted remote access
This manual covers the installation and configuration of the NETGEAR FVS338 ProSafe VPN Firewall 50, including the Smart Wizard, VPN Wizard, and web‑based management interface. It details supported protocols, security features such as SPI firewall, DoS protection, and IPSec VPN, as well as networking options like DHCP, PPPoE, and NAT.
Hardware specifications, environmental limits, warranty information, and a list of accessories are also provided, giving administrators a complete reference for deploying and maintaining the device in small‑business environments.
| Processor Speed | 266 MHz |
|---|---|
| Flash Memory | 16 Mb |
| Dimensions | 25.4 × 17.8 × 3.96 cm (10 × 7 × 1.56 in) |
| Weight | 1.7 kg (3.7 lb) |
| LAN Ports | Eight 10/100 Mbps auto‑sensing, Auto Uplink RJ‑45 ports |
| WAN Port | 10/100 Mbps Ethernet RJ‑45 |
| Serial Port | RS‑232 DB‑9 connector |
| Maximum VPN Tunnels | 50 IPSec tunnels |
| Maximum Users | 253 concurrent users |
| WAN‑to‑LAN Throughput | Up to 90 Mbps |
| Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Operating Humidity | Up to 90 % non‑condensing |
| Warranty | 3‑year NETGEAR warranty |
The device supports up to 50 IPSec VPN tunnels simultaneously.
It can achieve up to 90 Mbps WAN‑to‑LAN throughput.
The firewall can handle up to 253 concurrent users.
NETGEAR offers a three‑year warranty on the FVS338.
