Cypress CY8C29x66, CY8C27x43, CY8C24x94, CY8C24x23A, CY8C21x34, CY8C21x23 Development Tools Selector Guide

This file provides a selector guide for the Cypress PSoC development tools, including the PSoC Designer, PSoC Express, and PSoC Programmer.

Brand: Cypress
Category: Other Electronics
Document type: Product Leaflet
Language: English
Pages: 10
File format: PDF
File size: 581 KB
Published: 08 May, 2012
Updated: 30 September, 2023
MD5 checksum: E7EECEDC40E2F4083EF425806D42A3CE
PDF: Cypress CY8C29x66, CY8C27x43, CY8C24x94, CY8C24x23A, CY8C21x34, CY8C21x23 Development Tools Selector Guide PDF

About this manual

This guide provides an overview of Cypress PSoC development tools, including the basic and express development kits, emulation accessories, and programming methods. It describes the hardware blocks, software suites (PSoC Designer, PSoC Express, PSoC Programmer) and the various kits that support the listed CY8C family devices.

The document also details programming adapters (ISSP or MiniProg) required for different package types, lists third‑party programming tools, and includes an appendix with part numbers and pricing for emulation pods, flexcables, and foot kits.

What's inside

PSoC Development Tools Selector Guide
Basic Development Kit
Express Development Kit
Emulation Kits and Accessories
Evaluation Tools Overview
Programming Methods
3rd‑Party Tools
Appendix

Specifications

Supported PSoC devices	CY8C29x66, CY8C27x43, CY8C24x94, CY8C24x23A, CY8C21x34, CY8C21x23
Evaluation kit contents (MiniProg1)	MiniProg Programming Unit, MiniEval Socket Board, USB 2.0 Cable, device samples

Frequently asked questions

Where can I download PSoC Designer software?

PSoC Designer software is available for free download from the Cypress website.

Download PDF (581 KB)
