This document is about PC board layouts and wiring diagrams of V23100-V4024A011 suppliers. It provides layouts and wiring diagrams for the supplier's DIP and SIP versions. The product is available in various forms of single-pole single-throw and single-pole double-throw switches. Versions with electrostatic shield and diode are also available. The document also provides information on the dimensions and technical support of the product.
The 13C8100 relay datasheet from Tyco Electronics includes detailed electrical specifications, contact configurations, and mechanical dimensions for both DIP (flat) and SIP versions. It contains PC board layout and wiring diagram views, as well as part numbers for SPST‑1, SPDT‑1, and DPST‑2 forms.
The document also lists tolerances, pin pitch, and pad diameters, and provides technical support contact information for designers needing assistance.
| Pad diameter | 0.024 in ±0.004 (0.60 mm ±0.10 mm) |
|---|
Technical support is available at 1‑800‑522‑6752 or via www.pandbrelays.com.
