The catalog describes Tyco's fine‑pitch surface‑mount (SMT) stacking connectors designed for high‑density parallel board‑to‑board applications. It lists available connector sizes, stacking heights from 5 mm to 16 mm, and features such as bellows‑type spring contacts and positioning bosses for reliable mating.
Technical data include voltage and current ratings, contact resistance, dielectric withstand voltage, operating temperature range, and detailed part numbers for plugs, receptacles, and packaging options (tube, tape‑and‑reel, etc.). The document also references recommended PCB layout guidelines and related technical documents.
| Voltage Rating | 100 VAC |
|---|---|
| Current Rating | 0.5 A |
| Contact Resistance | 30 mΩ max (initial) |
| Dielectric Withstanding Voltage | 500 VAC (1 min) |
| Operating Temperature | -40 °C to +85 °C |
They are rated for 100 VAC.
Board‑to‑board stacking heights range from 5 mm to 16 mm in 1 mm increments.
The housing is made of high‑temperature thermoplastic, rated 94V‑0, with brass contacts plated with gold, tin, and nickel.
