MAX9206/MAX9208 are TI's high-speed serial bus low-voltage differential signaling (BLVDS) data stream deserializers that transform 10-bit-wide parallel LVCMOS/LVTTL data and clock into a serial BLVDS signal.
The MAX9206 and MAX9208 are 10‑bit LVDS deserializers that convert high‑speed BLVDS serial data streams into parallel LVCMOS/LVTTL data and clock. They operate from a single +3.3 V supply, support automatic clock recovery, and include a power‑down mode that reduces supply current to less than 600 µA.
The devices are offered in a 28‑pin SSOP package, operate from –40 °C to +85 °C, and support data rates up to 450 Mbps (MAX9206) or 600 Mbps (MAX9208). Detailed electrical characteristics, pin descriptions, layout recommendations, and typical application topologies are provided.
| Supply Voltage | +3.3 V |
|---|---|
| Operating Temperature Range | -40 °C to +85 °C |
| Package | 28‑pin SSOP |
| Maximum Data Rate (MAX9206) | 450 Mbps |
| Reference Clock Range (MAX9206) | 16 MHz – 45 MHz |
| Power‑Down Supply Current | < 600 µA |
| Jitter Tolerance (MAX9206 @ 40 MHz) | 720 ps (p‑p) |
Both devices operate from a single +3.3 V supply.
In power‑down mode the supply current is reduced to less than 600 µA.
They are specified for operation from –40 °C to +85 °C.
