The Lattice ispXPGA Family of radio solutions is a series of SRAM-based FPGAs that offer ultra-fast boot time, easy configuration, and high performance. The family features up to 1.25M system gates and up to 496 I/O, making it ideal for high-performance, reconfigurable wireless and communications applications.
The ispXPGA family from Lattice Semiconductor provides high‑performance, non‑volatile FPGA devices that can be re‑configured in milliseconds. They combine Electrically Erasable CMOS (E²CMOS) memory with SRAM cells, allowing instant‑on operation and secure designs without external configuration memory.
The devices support a wide range of system gates (up to 1.25 M), I/O pins (up to 496), and voltage supplies (1.8 V, 2.5 V, 3.3 V). They include sysMEM embedded RAM blocks, sysCLOCK PLLs, and sysHSI high‑speed serial interfaces with up to 20 channels per device, enabling clock speeds from 10 MHz to 320 MHz.
| Supported supply voltages | 1.8 V, 2.5 V, 3.3 V |
|---|---|
| Clock operation range | 10 MHz – 320 MHz |
| Package type (largest device) | 900‑ball fpBGA |
It uses Electrically Erasable CMOS (E²CMOS) memory cells for non‑volatile capability.
The devices operate from 1.8 V, 2.5 V, or 3.3 V power supplies.
They can run at frequencies up to 320 MHz.
Up to 20 high‑speed serial (sysHSI) channels are available per device.
