The TS9013 is a integrated circuit from TSZ company, which has the characteristics of low power consumption, low dropout voltage and high output voltage accuracy. This product is widely used in portable devices and large current applications.
The TS9013 series is a positive voltage regulator built with CMOS technology, offering very low power consumption, low dropout voltage, and high output voltage accuracy. It is available in 3‑pin SOT‑89 and SOT‑223 packages and includes thermal shutdown and current fold‑back protection for reliable operation in portable and high‑current applications.
Key specifications include a typical dropout voltage of 0.4 V at 500 mA load, output current up to 500 mA, quiescent current of 2 µA typical at 5 V output, and output voltage tolerance of ±2 %. The datasheet also provides absolute maximum ratings, electrical characteristics, and detailed mechanical drawings for both package types.
| Dropout voltage (typical) | 0.4 V @ 500 mA |
|---|---|
| Quiescent current | 2 µA typ @ Vo=5V |
| Output voltage tolerance | ±2 % |
| Thermal shutdown voltage options | A=1.5 V, D=1.8 V, K=2.5 V, S=3.3 V, 5=5.0 V |
The typical dropout voltage is 0.4 V at a 500 mA load.
The quiescent current is about 2 µA typical when the output is 5 V.
Thermal shutdown can be set to A=1.5 V, D=1.8 V, K=2.5 V, S=3.3 V, or 5=5.0 V.
