NTS350 Series is an embedded power supply for business-critical continuity. It features active power factor correction, IEC EN6100-3-2 compliance, remote sense, power fail and remote inhibit, single wire current sharing, built-in EMI filter, low output ripple, 5V standby, 12V fan output, overvoltage protection, overload protection, thermal overload protection, DC power good, built-in OR-ing diode/FET, and optional fan cover (-CF suffix).
The NTS350 Series from Emerson Network Power is a compact, single‑output UPS designed for business‑critical continuity. It delivers 200‑350 W total power and includes features such as active power‑factor correction, built‑in EMI filtering, and remote‑sense capability.
Key specifications include a wide input voltage range of 85‑264 VAC (120‑300 VDC), 85% typical efficiency at full load, standby 5 V @ 2 A, fan output 12 V @ 1 A, and robust protection mechanisms like overload, over‑voltage and short‑circuit protection. The unit operates from 0 °C to 50 °C ambient, stores from –40 °C to +85 °C, and meets multiple safety standards (UL, CSA, TUV, etc.).
| Total Power | 200 - 350 Watts |
|---|---|
| Input Voltage (AC) | 85-264 VAC |
| Input Voltage (DC) | 120 - 300 VDC |
| Number of Outputs | Single |
| Efficiency | 85% typical at full load |
| Standby Output | 5V @ 2A regulated |
| Fan Output | 12V @ 1A |
| Operating Temperature | 0°C to 50°C ambient |
| Storage Temperature | -40°C to +85°C |
| MTBF | 1M hours at full load, 25°C |
The NTS350 Series accepts an AC input voltage of 85‑264 VAC and a DC input voltage of 120‑300 VDC.
It provides a total power output ranging from 200 W to 350 W.
The unit achieves about 85% efficiency at full load.
The UPS operates from 0 °C to 50 °C ambient temperature.
