This is a high intensity LED, model is TLHF5800, color temperature is soft orange, the viewing angle is very small, suitable for scenes that require high brightness and small viewing angle.
The TLHF5800 is a high‑intensity orange LED built with AlInGaP technology and housed in a 5 mm untinted non‑diffused plastic package. Its very small viewing angle delivers extremely high luminous intensity, making it suitable for status lights, indicators, lightpipes, outdoor displays, medical instruments, maintenance and legend lights.
The datasheet lists absolute maximum ratings, typical optical and electrical characteristics, and package dimensions. Key parameters include a luminous intensity of 1 000‑3 500 mcd at 20 mA, a forward voltage of about 22.6 V, and a small half‑intensity angle of roughly 4°. The device is lead‑free and designed for both DC and high‑peak current operation.
| Luminous intensity (20 mA) | 1 000‑3 500 mcd |
|---|---|
| Dominant wavelength (10 mA) | 598‑605 nm |
| Forward voltage (20 mA) | 22.6 V |
| Reverse voltage | 5 V |
| Junction temperature (max) | 100 °C |
| Operating temperature range | -40 °C to +100 °C |
| Storage temperature range | -55 °C to +100 °C |
| Surge forward current (≤10 µs) | 0.1 A |
It can handle a surge forward current of up to 0.1 A for pulses of 10 µs or less.
Yes, the device is specified as lead‑free.
It is suitable for status lights, OFF/ON indicators, lightpipes, outdoor displays, medical instruments, maintenance lights, and legend lights.
