The Optoway APD-1350 is a high-performance photodiode that can be used in long-distance fiber-optic communications systems. It has a data rate of up to 2.7 Gbps, a typical responsivity of 0.9 A/W, a typical breakdown voltage of 40 V, a wide wavelength range of 1260-1620 nm, and a operating temperature of -40 to 85 oC.
The Optoway APD-1350 is a mini‑size InGaAs avalanche photodiode with a single‑mode pigtail, designed for long‑distance fiber‑optic communication. It offers a data rate up to 2.7 Gbps, typical responsivity of 0.9 A/W, and operates from –40 °C to 85 °C.
Key specifications include a breakdown voltage of 40 V (typical), wavelength range of 1260‑1620 nm, and a 9/125 µm single‑mode fiber connector. Mechanical dimensions, pin assignments, and ordering information are provided for integration into optical modules.
| Data Rate | up to 2.7 Gbps |
|---|---|
| Responsivity (typical) | 0.9 A/W |
| Breakdown Voltage (typical) | 40 V |
| Wavelength Band | 1260 nm – 1620 nm |
| Operating Temperature | -40 °C to 85 °C |
| Fiber Type | 9/125 µm Single‑Mode |
| Detection Range | 1260 nm – 1620 nm |
| Responsivity at 1550 nm | 0.85 A/W |
| APD Forward Current (max) | 2 mA |
| APD Reverse Current (max) | 3 mA |
| Storage Temperature | -40 °C to 85 °C |
The APD-1350 supports data rates up to 2.7 Gbps.
Its typical responsivity is 0.9 A/W.
It operates from –40 °C to 85 °C.
The typical breakdown voltage is 40 V.
