These high intensity white LED lamps are based on InGaN material technology. A blue LED die is coated by phosphor to produce white.
The HLMP-CWxx family of high‑intensity white LED lamps uses InGaN technology with a blue die coated by phosphor to produce untinted white light. The lamps feature well‑defined spatial radiation patterns and are available with viewing angles of 15°, 23°, and 30°.
Key specifications include forward voltage around 4 V at 20 mA, peak pulsed forward current of 100 mA, and operating temperature range from –40 °C to +85 °C. The devices are moisture‑resistant, Class 1 ESD sensitive, and suitable for electronic signs, backlighting, and general‑purpose indicators.
| Reverse voltage | 5.0 V |
|---|---|
| DC forward current | 30 mA |
| Power dissipation | 105 mW |
| LED junction temperature | 110 °C |
| Operating temperature range | -40 °C to +85 °C |
| Viewing angle | 15°, 23°, 30° |
The lamps are offered with viewing angles of 15°, 23°, and 30°.
Yes, they have superior resistance to moisture.
They are Class 1 ESD sensitive, so appropriate ESD precautions must be observed.
The DC forward current is limited to 30 mA, with a peak pulsed forward current of 100 mA.
