i3Controller is a new concept in control, providing the user with high performance Operation Interface, fast and effective Control Engine, and open Bus communications in one box. The unique case design of i3 allows for panel or DIN rail mounting, offering ultimate flexibility in controller positioning. i3 features a LED backlit LCD display with graphics and text capabilities, with an IP65 (NEMA4) programmable keypad for control input. It includes a mix of digital and analogue I/O, including T/C and PT100 inputs, making it ideal for process control applications. i3 interfaces directly to IMO Smart I/O, expanding capabilities and providing greater flexibility in system design. It also features two multi-function serial communications ports that can be used for programming, expansion I/O, and modem connection. i3 comes with advanced controls such as PID, PWM, MODEM, Alarm, Ethernet, and Recipe functions and is supported by FREE Software and the unique IMO 3-year warranty. i3 is the ultimate integrated control solution.
The IMO i3 controller is an integrated control solution that combines a high‑performance operation interface, a fast control engine, and open bus communications in a single box. It offers a LED‑backlit 128 × 64 LCD display, programmable keypad, and a flexible mounting design for panel or DIN‑rail installation.
The device provides a mix of digital and analogue I/O, including temperature‑compensated (T/C) and PT100 inputs, two multi‑function serial ports, Ethernet, and an optional built‑in modem. It supports advanced functions such as PID, PWM, alarm, recipe management, and includes free configuration software and a three‑year warranty.
| Display | 128 × 64 STN LCD, LED backlit |
|---|---|
| Digital Inputs | Up to 24 (direct) |
| Analogue Inputs | Up to 4 (direct) |
| Digital Outputs | Up to 16 (direct) |
| Analogue Outputs | Up to 2 (direct) |
| Communication Port 1 | RS232 / RS485 |
| Ethernet | Integrated Ethernet port |
| Panel Size | 96 × 96 × 60 mm (DIN‑96) |
It uses a 128 × 64 STN LCD with LED backlighting.
The controller provides up to 24 direct digital inputs.
Yes, an integrated Ethernet port is provided.
