This document describes the features and characteristics of the EMECH specialist power relay SRF I 1 Form C (SPDT). The relay has a high sensitivity coil, flux and fully sealed versions available, CUR recognized, short operate and release time, and a nominal operating power of approximately 200mW.
This document describes the IMO SRF power relay, a Form C (SPDT) device available in flux and fully sealed versions. It features a high sensitivity coil with a nominal operating power of approximately 200mW and is recognized by CUR.
| Contact form | 1 Form C (SPDT) |
|---|---|
| Coil power | 200mW |
| Contact material | Ag + gold flash |
| Operate time | 10ms Max |
| Ambient temperature | -25~+55°C |
| Weight | 4g |
| Maximum switching power | 240VA (360VA) |
The maximum switching power is 240VA or 56W.
The maximum switching voltage is 120VAC or 60VDC.
The maximum carrying current is 3A.
