This document introduces a single-phase AC drive and a three-phase AC drive, with power ranges of 0.4-2.2KW and 0.4-7.5KW respectively. This series of products have high starting torque, intelligent functions, and enhanced maintenance/protection functions.
This manual covers the Jaguar VXSM series of industrial inverters, ranging from 0.4 kW single‑phase units to 7.5 kW three‑phase models. It details the features, protective functions, and advanced options such as torque‑vector control, on‑delay compensation, and PID flow control.
Installation, wiring, and safety guidelines are included, with recommendations for remote‑control wiring lengths, motor protection, and compliance with UL, cUL, TUV, CE and EMC directives. Warranty information and technical support contacts are also provided.
| Maximum Power | 7.5 kW |
|---|---|
| Single‑phase Voltage | 200 V (up to 2.2 kW) |
| Three‑phase Voltage | 400 V |
| Operating Temperature Range | -10 °C to 50 °C |
| Maximum Remote‑control Wiring Length | 20 m |
| Maximum Motor Wiring Length (≤3.7 kW) | 50 m |
It is covered by a 5‑year warranty against failure due to inferior material or workmanship.
The inverter conforms to UL, cUL, TUV, CE and the EMC Directive when used with an optional filter and shielded motor cable.
The wiring between the inverter and the operator box should not exceed 20 m and should use twisted shielded cable.
Yes, but only with a pre‑approved combination of motor and inverter; contact IMO for details.
