ADL5812 is a dual high IP3, 700 MHz to 2800 MHz, double balanced, passive mixer, IF amplifier, and wideband LO amplifier
The ADL5812 provides a broadband passive mixing solution with a 700 MHz to 2800 MHz RF range and a 250 MHz to 2800 MHz LO range. It delivers 6.7 dB power conversion gain, 27.2 dBm input IP3, and 12.5 dBm input P1dB while operating from a single 3.6 V‑5.5 V supply.
All functions are programmed via a 3‑wire serial port interface, and the device is offered in a 40‑lead LFCSP package. An evaluation board and detailed pin configuration are provided for rapid prototyping and system integration.
| RF Frequency Range | 700 MHz – 2800 MHz |
|---|---|
| Power Conversion Gain | 6.7 dB |
| Input IP3 | 27.2 dBm |
| Input P1dB | 12.5 dBm |
The ADL5812 operates from 700 MHz to 2800 MHz on the RF input.
All functions are controlled via a 3‑wire serial port interface.
