TSic™ is a leading-edge digital temperature sensor IC, combining outstanding accuracy with fast response and long-term stability. The device is very simple to use, fully tested and calibrated for accuracy on delivery – no further calibration is needed. TSic™ is available in different accuracy classes and provides an absolute analog voltage output (0 to +1V) or an 11bit digital output at the one-wire serial interface. TSic™ is specifically designed for high-performance, cost-effective temperature sensing in medical instruments, industrial process control, automobiles, building automation, white goods, office equipment and mobile measurement devices.
The TSic™ temperature sensor IC family offers best‑in‑class accuracy (±0.1 °C), fast response, low current consumption and long‑term stability. Available in analog voltage (0‑1 V) or 1‑bit one‑wire digital output, the devices require no external trimming or customer calibration.
TSic sensors are suited for a wide range of applications including industrial process control, automotive climate control, medical instrumentation, white‑goods, HVAC, and portable battery‑operated devices. Various package options (TO‑92, SOP‑8, COF, bare die) and accuracy classes are offered, with ordering codes for bulk, tube, and focused temperature ranges.
| Supply voltage | +2.97 to +5.5 V (TSic 106, 206, 306); +4.5 to +5.5 V (TSic 101, 201, 301, 506) |
|---|---|
| Measurement range | -50 °C to +150 °C |
| Typical current consumption | ≈45 µA |
| Output type | Analog voltage 0‑1 V or 1‑bit one‑wire digital |
TSic 106 operates from +2.97 V to +5.5 V.
They can measure from –50 °C up to +150 °C.
TSic provides an absolute analog voltage output (0‑1 V) or a 1‑bit digital one‑wire interface.
Typical current consumption is about 45 µA.
