This document introduces a general purpose AC drive that is available in single phase and three phase versions, with power ranges from 0.4 to 7.5 kW. This series of products features high starting torque, intelligent functions, and maintenance/protection functions. The dynamic torque-vector control system ensures optimal control of maximum output torque. Ideal for heavy load starting.
The IMO Jaguar VXSM series offers compact, high‑performance inverters for a wide range of industrial applications. Available in three‑phase 400 V and single‑phase 200 V versions, the series covers power ratings from 0.4 kW up to 7.5 kW, with uniform height dimensions of 130 mm for easy panel integration.
Key features include built‑in inrush‑current suppression, optional braking resistor, torque‑vector control, on‑delay compensation to reduce motor wow, and extensive protective functions such as over‑heat warning and phase‑loss detection. The leaflet also provides wiring guidelines, safety notes, and a 5‑year warranty policy.
| Power rating range | 0.4 kW – 7.5 kW |
|---|---|
| Input voltage | 200 V single‑phase, 400 V three‑phase |
| Height dimension | 130 mm (uniform for models up to 4.0 kW) |
| Built‑in braking transistor | Standard, optional external braking resistor |
| IP rating (future) | IP54 (water‑proof models forthcoming) |
IMO Jaguar drives are covered by a 5‑year warranty against material or workmanship failures.
Yes, but a quality motor is recommended; an output circuit filter may be required for standard motors.
