This document describes the specifications and features of the PC1604LRU-AWB-H product.
This datasheet describes the PC1604LRU-AWB-H LCD module, covering its features, mechanical dimensions, electrical ratings, optical performance, and backlight characteristics. It also includes quality assurance procedures, reliability test conditions, and safety and handling precautions.
Key information includes the display type (16×4 characters), LCD type (STN YG Positive Transflective), outline dimensions (87 mm × 60 mm × 14 mm), operating temperature range (‑20 °C to 70 °C), and LED backlight with a forward current of up to 550 mA. The document also outlines warranty terms and recommended storage conditions.
| Display Type | 16×4 Characters |
|---|---|
| LCD Type | STN YG Positive Transflective Extended Temp. |
| Outline Dimension | 87.0 mm × 60.0 mm × 14.0 mm (max) |
| Power Supply Voltage | Vpp –0.3 V to 7.0 V |
| Logic Supply Voltage | Vpp 5.0 V to 5.5 V |
| Operating Temperature | -20 °C to 70 °C |
| Viewing Angle | 40° |
| Contrast Ratio | 5 to 7 |
| Response Time (rise) | 150 ms |
| Backlight Forward Current | 550 mA (max) |
| Warranty Period | 13 months from shipping |
The outline dimension is 87.0 mm (L) × 60.0 mm (W) × 14.0 mm (H) (maximum).
The module can operate from –20 °C to 70 °C.
It uses an LED backlight.
The warranty period is thirteen months from the date of shipping.
